Features
Edge Banding:
1.Anti-ergonomic folding arm design, rotating structure, flexible and convenient curve edge trimming, large pieces without trimming edge sealing and handling, fast and efficient.
2.Touch screen: clear markings, easy to operate, free to operate as needed.
3.Gluing assembly: Grid-like gluing rollers, even gluing, firm bonding, large-capacity glue pot.
4.Fitting wheel: Adjust according to the width of the sealing strip, prevent the sealing strip from deviation, with the auxiliary pressure wheel, the sealing strip is pressed and pasted twice to increase the firmness of the adhesion.
5.Hot air assisting: Heating the edge sealing strip to improve the adhesive force between the strip and the board.
6.Automatic glue clearing, automatic spraying glue clearing agent, the laminating wheel is not easy to glue, to ensure the sealing effect.
Edge Trimming:
1.Edge trimming and scraping: Upper and lower trapezoidal edge trimming knife design, with double-sided flexible scra ping, scraping with the movement, scraping off the excess stranded wire and trimming volume, improve work efficiency.
2.Automatic glue removal: Double-sided automatic spraying glue removal agent, effectively help scrape off the glue now, and lubricate the plate to prevent scratching the plate.
3.Air floating profiling column: The profiling column device automatically closes, fixing the sheet while preventing scratches.
4.Plate thickness adjustment valve: Suitable for plate thickness 14-70mm, according to their own flexible adjustment of the plate.
5.Imitation power wheel: Provide uniform forward force when trimming, make the trimming of shaped boards more smooth and fluent.
6.Photoelectric sensor: 5 seconds after the sensor can not be plate, automatically stop working, energy saving and prevent workers from accidental injury.
Parameters
Power supply voltage | 220V/50Hz | Thickness of trimming plate | <14mm single side trimming, 14-70mm upper and lower double trimming (related to trimming knife) |
Total power | 5.1kW | Inner arc radius | ≥20mm (special operation can seal the radius 4mm) |
Air pressure | 0.6-0.8Mpa | Edge banding speed | 0-18cm/s |
Glue pot capacity | 1200ml | Profiling speed | 0-24cm/s |
Glue pot temperature | 130℃-180℃ | External vacuum cleaner | Φ100mm Air volume: 9800m³/h |
Hot melt adhesive type | EVA | Types of edge banding | PVC, veneer (need to be customized), plastic, melamine, etc. |
Edge banding width | 8-50mm | Packing size | 180X135X139cm (half wooden box) 182X137X148 (full wooden box) |
Edge banding thickness | 0.4-2mm (related to edge banding material) | Weight | 350kg |
Effect
Details
Touch screen
clear markings, easy to operate, free tooperate as needed.
Hot air assisting
Heating the edge sealing strip toimprove the adhesive force between thestrip and the board.
Multiple limits
It can be adjusted according to the sealingwide strip to prevent the sealing edge fromshifting up and down and ensure the sealingedge is smooth.
Photoelectric sensor
5 seconds after the sensor can not be plate,automatically stop working, energy savingand prevent workers from accidental injury.
Board thickness adjustment
uitable for plate thickness 14-70mm,according to their own flexible adjustment ofthe plate.
Trapezoidal knife
Upper and lower trapezoidal edgetrimming knife design, with double-sidedflexible scra ping, scraping with themovement, scraping off the excessstranded wire and trimming volume,improve work efficiency.
